SPECIFICATIONS

Brand Name: DAWEI

Hign-concerned Chemical: None

Target Pet: Dog & Cat

Features:

- 12.1" color LCD display, full viewing angle display, high resolution 1024*768;

- Standard parameters: ECG, blood oxygen, blood pressure, respiratory rate, body temperature, heart rate;

- Double overvoltage protection of blood pressure software and hardware to ensure monitoring safety;

- Fanless design prevents hair debris from getting caught in the equipment, without cross-infection, protecting the health of animals and doctors;

- Blood oxygen measurement is a weak perfusion technology developed based on the characteristics of animal pulse, which has excellent anti-interference;

- Frequency response 0.05-150Hz, heart rate measurement upper limit 500 times/minute, designed for animals with high heart rates;

- A very short boot time of 6 seconds to enter the working state;

- NIBP uses pulse wave measurement technology to display the measurement process in real time and has an absolute basis for judging the accuracy of the measurement results;

- With auxiliary vein puncture and accurate measurement functions;

- Supports ≥36 hours of ECG waveform playback;

- Simple and efficient interface display, standard interface, large fonts, respiratory oxygenation diagram, trend coexistence, seven-lead ECG on the same screen;

- Visual alarm function to improve monitoring efficiency;

- Parameter color adjustment function, the operator can customize the color of waveforms and fonts;

- The alarm sound and the pulse rate sound are independent. The pulse rate sound continues to respond when the alarm is muted. The alarm sound can be activated normally when the pulse rate sound is muted;

- Resistant to defibrillation, electrosurgery, power grid, and myoelectric interference;

- Large-capacity built-in lithium battery, continuous working time ≥ 240 minutes;

- Low battery alarm, no data will be lost at critical moments;

- Large-capacity storage capacity: can meet the data storage requirements of at least 800 hours of continuous monitoring of sick animals;

- Optional built-in thermal array recorder with three waveform tracings;

- Reserved ETCO2 interface to support plug-and-play carbon dioxide module;

Functions:

- Standard parameters for this veterinary monitor: ECG, Oximetry, Blood pressure, Respiratory rate, Temperature, and Heart rate.

- It has abundant functions, such as audible and visual alarm, trend data storage and output, NIBP measurement, alarm event marking, etc.

- Warranty: 2 years for the main unit and half a year for accessories.
